Digital signage with CMS FUNCTION BY Local files
Support image and video slideshows, and allows switching between different program groups for playback using a remote control.
Digital signage USB local update solution
It provides a low-cost, highly reliable and extremely easy-to-operate digital signage content update and broadcast control solution for scenarios that do not have a network environment or have extremely high requirements for network security
in project
Overview of the Plan
This solution is based on commercial display screens equipped with high-performance RK3566 chips and pre-installed with customized CMS broadcast control systems. Users only need to save the multimedia files to a USB flash drive according to the rules, insert it into the device, and the update will be automatically completed. They can also switch between multiple preset program groups with one click on the remote control, achieving centralized and flexible management of content.
It is highly suitable for use in environments such as factory workshops, confidential units, remote stores, and public transportation where there is no network or the network is unstable. It solves the pain points of traditional digital signage systems, such as reliance on the network, complex operation, and high maintenance costs.
Core functional features
Offline update, safe and reliable
Completely disconnected from the Internet, update content via a local USB flash drive, eliminating the risk of network attacks, suitable for any environment.
The operation is extremely simple and requires no training
The entire operation can be completed in just three steps: "Copy - paste - remote control selection", and any employee can quickly get started.
Program grouping and flexible broadcast control
Up to 9 program groups can be preset (corresponding to the number keys 1-9 on the remote control), easily meeting the needs of different scenarios.
Wide compatibility
Supports mainstream image and video formats to meet various content display requirements.
Automatic broadcast control
It starts automatically upon startup without the need for manual intervention, enabling 24/7 unattended operation.
Cost optimization
Streamline non-essential functions and provide the most cost-effective solutions.
Product specification parameters
| Specification parameters | Detailed description |
|---|---|
| Display screen | 10.1-inch high-definition industrial display screen |
| Processor | RK3566 |
| Memory and Storage | 2GB RAM + 16GB ROM |
| Operating system | Android 11 |
| Interface configuration | USB interface, power interface, audio interface（No touch, No camera,No PoE） |
| Special features | Local update via USB flash drive, remote control, automatic startup upon startup, and group playback of programs |
Operating Guide
Three simple steps to manage your digital signage content with ease
1
Prepare a USB flash drive
Create a folder named "rplay" in the root directory of the USB drive. Within this folder, create a numbered folder (1-9) and place the media files in the corresponding folder.
2
Updated content
Insert the USB flash drive into the USB port of the device, and the system will automatically recognize and copy the contents. After the update is completed, unplug the USB drive.
3
Playback control
Use the remote control to press the number keys (1-9) to switch and play the corresponding program group. By default, the contents of folder 1 are played upon startup.
Method for clearing content
To clear the contents of the device, simply copy an empty rplay folder to a USB drive and insert it into the device.
